Switch socket ZI2 with disconnector L-O-P (SCHUKO)
Switch sockets ZI SCHUKO
ZI#
EAN:
Note: 1-phase side socket in installed on the right by default. It is possible to order the side socket on the left. In order to do that, please add "L", e.g. ZI23\R111L-S
In assemblies: ZI25\R361-S, ZI25\R362-S, ZI25\R461-S, ZI25\R462-S it is possible to protect the side socket with a fuse-link WTA 10A/250V 1500 A AC.
The units have modern and ergonomic design. Each unit is fitted with a main socket 16 or 32 A (depending on configuration). Switch sockets ZI with L-0-P disconnector are fitted with a cam switch, a main socket and, depending on configuration, 1 or 2 side sockets (1-phase) fitted on the base plate which makes connecting the wires easier. Switch sockets ZI are compliant with the standard: PN-EN 60439-3, PN-EN 60439-1
New devices are compliant with RoHS Directive 2002/95/EC which means that they do not contain the hazardous substances listed in the Directive.
New devices are compliant with RoHS Directive 2002/95/EC which means that they do not contain the hazardous substances listed in the Directive.
| Rated insulation voltage Ui | 500 V |
| Prąd znamionowy zestawu InA | max 32 A |
| Rated frequency | 50-60 Hz |
| Rated switching voltage Ue | 230/400 V |
| Rated withstand impulse voltage Uimp | 6 kV |
| Wire gauge | 2.5...6 mm² |
| Degree of protection | IP44 |
| Protection class | II |
| Weight | 0.8...1.2 kg |
| Gland type | M25×1.5 (16 A) M32×1.5 (32 A) |
.png) |
2P+PE 16A |
 |
2P+PE 16A side socket |
.png) |
3P+N+PE 16A |
.png) |
3P+N+PE 32A |
.png) |
3P+PE 16A |
.png) |
3P+PE 32A |
 |
Switch L-0-P |
